Manufacturer Data:
„Phantom“ Multicoated Focal length: 5, 6, 7, 9, 12.5 and 18mm Apparent field of view: 40° 4 lenses in two groups (orthoscopic design, one triplet and a single
eye lens) Barrel size: 1,25“ This series is parfocal. You do not need to readjust the focus more
than a bit when changing the focal length.. |
|
Comments:
The orthoscopic design is famous for planetary observations since a long
time. By using just e few lenses between the object and the observer this
design allows maximum sharpness on the optical axis, but also good sharpness at
the edges. A drawback is just the eye relief, which is comparable to those of
the standard Plossl design, and which makes the eyepieces not suitable for
eyeglass wearers.
The Baader orthoscopic eyepieces are of fine quality. They are blackend
inside, a really good manufactured field stop, which makes the edges of the
apparent field of view as sharp as a razor blade and suppress reflexes very
effective.
The eyepieces one by one:
Art.-Nr.: BA-OR-05 Price: 98,00 € 5mm orthoscopic eyepiece |
|
Art.-Nr.: BA-OR-06 Price: 98,00 € 6mm orthoscopic eyepiece |
|
Art.-Nr.: BA-OR-07 Price: 98,00 € 7mm orthoscopic eyepiece |
|
Art.-Nr.: BA-OR-09 Price: 98,00 € 9mm orthoscopic eyepiece |
|
Art.-Nr.: BA-OR-12.5 Price: 98,00 € 12,5mm orthoscopic eyepiece |
|
Art.-Nr.: BA-OR-18 Price: 98,00 € 18mm orthoscopic eyepiece |
|
